Illuminated signs and letters from HUBER Signage
There are a lot of implementation possibilities for illuminated advertising in- and outdoor. Via the illuminated advertising of HUBER Signage you show your customers impressively who you are and where you are. Our illuminated signs and letters are produced according to your exact need – for the optimal and sustainable impact of your message.
Configuration of illuminated advertising
It is possible to implement illuminated signs and letters in different ways regarding the light source, materiality and construction. Subsequently you can find an overview about the well-established implementations. Partially different ways can also be combined.
Illuminated letters: Systems and implementation ways
3D letters set striking accents and, unlit or with integrated lighting, ensure maximum attention day and night. The different versions offer a wide range of design options – individually tailored to your brand identity and architectural conditions.
Aluminium letters,
non-illuminated
- Profil 1
- Cap height 200 – 3000 mm
- Laser-cut aluminium or stainless steel fronts
- Side panels made of aluminium or stainless steel
- Colouration as desired
- Overall depth from 30 mm
Letters,
non-illuminated
- Profil 2
- Cap height 50 – 1500 mm
- PET or metal contour cut
- Colouration as desired
- Overall depth 2 – 20 mm
Illuminated letters,
back side illumination
- Profil 3
- Cap height 250 – 2500 mm
- Laser-cut aluminium or stainless steel fronts
- Side panels made of aluminium or stainless steel
- Acrylic glass bottom on the back
- Elegant corona effect thanks to internal LED technology
- Colouration as desired
- Overall depth from 40 mm
Illuminated letters,
front side illumination
- Profil 4
- Cap height from 800 mm
- Laser-cut aluminium back panel
- Side panels made of aluminium
- Acrylic glass fronts, inserted tension-free in angle frames
- Optimal illumination via internal LED components
- Colouration as desired
- Overall depth from 100 mm
Illuminated letters,
front side illumination
- Profil 5
- Up to a cap height of 1000 mm
- Laser-cut aluminium back panel
- Side panels made of aluminium
- Acrylic glass fronts glued to a plastic frame
- Optimal illumination via internal LED components
- Colouration as desired
- Overall depth from 80 mm
Illuminated letters,
frameless
- Profil 6
- Up to a cap height 400 mm
- Laser-cut aluminium back panel
- Side panels made of aluminium
- Laser-cut acrylic glass fronts
- Elastic adhesive connection to the frame
- Optimal illumination via internal LED components
- Colouration as desired
- Overall depth from 40 mm
Imitation of neon light letters
- Profil 7
- Cap height 250 – 2500 mm
- Aluminium fronts with milled and pushed throug light slit
- Light slit backed with acrylic glass = neon effect
- Side panels made of aluminium
- Optimal illumination via internal LED components
- Colouration as desired
- Overall depth from 60 mm
Illuminated letters,
front and side panel illumination
- Profil 8
- Cap height 200 – 1200 mm
- Laser-cut PVC back panel 6 – 12 mm
- Front and side panels made of acrylic glass, glued
- Optimal illumination via internal LED components
- Colouration according to acrylic glass fan
- Overall depth from 80 mm
Illuminated letters,
front side illumination
- Profil 9
- Cap height 200 – 1200 mm
- Laser-cut PVC back panel 6 – 12 mm
- Front and side panels made of acrylic glass, glued
- Side panels made of opaque acrylic glass
- Optimal illumination via internal LED components
- Colouration according to acrylic glass fan
- Overall depth from 80 mm
Illuminated signs: Systems and implementation ways
Illuminated signs are powerful carriers of your advertising message – visible, memorable and versatile in their configuration. Different system solutions enable targeted use indoors and outdoors and create a convincing appearance through shape, technology and design.
Illuminated sign one-sided
- For small and medium formats up to approx. 3000 x 1000 mm
- Back panel made of 3-4 mm aluminium composite plates
- Frames made of extruded aluminum profile
- Front made of 4 mm acrylic glass
- Printed or designed with foils
- Optimal illumination via internal LED components
- Overall depth from 100 mm
Illuminated sign double-sided
- For small and medium formats up to approx. 3000 x 1000 mm
- Frames and inner structure made of extruded aluminum profile
- Front and back panel made of 4 mm acrylic glass
- Printed or designed with foils
- Optimal illumination via internal LED components
- Overall depth from 180 mm
Illuminated sign one-sided
- For large formats up to approx. 50 x 5 m
- Frames and inner structure made of 2 mm aluminum
- Frames made of extruded aluminum profile
- Front made of pressure cloth
- Printed or designed with foils
- Optimal illumination via internal LED components
- Overall depth from 220 mm
Illuminated sign double-sided
- For large formats up to approx. 20 x 2 m
- Inner structure made of aluminum tubes
- Frames made of extruded aluminum profile
- Front and back side made of pressure cloth
- Printed or designed with foils
- Optimal illumination via internal LED components
- Overall depth from 250 mm
Illuminated sign frameless
- Available in any size for indoor use
- Back panel made of 3-4 mm aluminium composite plates
- Frames made of aluminum profile
- Front made of stretch cloth with piping
- Design with 4C printing
- Optimal illumination via internal LED components
- Overall depth from 40 mm
Illuminated sign cut out and pushed through
- For small and medium formats up to approx. 4000 x 2000 mm
- Case made of aluminium
- Illuminated elements/letters milled and pushed through
- Optimal illumination via internal LED components
- Overall depth from 60 mm
Customized illuminated sign
- For small and medium format
- Back panel made of laser-cut aluminium composite plates
- Frames made of aluminum profile for acrylic glass or pressure cloth
- Printed or designed with foils
- Optimal illumination via internal LED components
- Overall depth from 80 mm
Illuminated sign one-sided, flush-mount
- Any size possible
- Back panel and inner structure made of 2 mm aluminum
- Frames made of extruded aluminum profile
- Front made of pressure cloth
- Printed or designed with foils
- Optimal illumination via internal LED components
- Overall depth from 120 mm
- For flush installation in facade niches
This is essential in illuminated advertising:
Apart from the costs, these factors play a big role:
- Brilliance of colour
- Even illumination
- Effectiveness in advertising
- Costs of electricity and maintenance (optimal control systems, SICO)
- Weather resistance and lifetime
Environmental friendliness is another significant key fact:
- Light pollution
- Biodiversity
- PVC-free foils
- Indirect illumination
- Solar electricity supply
We have an experience over 60 years and 10.000 provided projects
The power of light – successfully utilized with HUBER Signage
Light is pure magic; it triggers emotions and creates vibes. Our illumination solutions enable unique effects which present your brand names and logos spectacularly. In each project we pay attention about the big picture. Our stagings harmonize with architecture, nature, environment and, of course, meet all legal requirements. We offer:
Consulting and planning
Conception, visualisation, construction, companionship in approval processes, advertising concepts in collaboration with architects and agencies, own structural engineers and technical teams
In-house production
Metalworking (laser cutting, milling, bending, etc.), steel construction and thin sheet metal, digital printing, wrapping, varnishing, acrylic glass processing, production and installation of LED-components
Installation and maintenance
In-house installation and service teams, precise, fast and professional, operating nationally and internationally
